Allen Bradley MPS-B330P-M-X156 servo motor

The MPS-B330P-M-X156 is a Kinetix AC servo motor from the MPS series of stainless steel servo motors. This device is specially designed for installation in washdown environments. It is constructed with rotors capable of withstanding high-pressure and highly caustic wash-down applications. This type of servo motor supports applications such as food, beverage, brewing, dairy, pharmaceutical, and health and beauty manufacturing equipment - all requiring adherence to strict sanitary compliance. The MPS-B330P-M-X156 has rated output power of 1.3 kW, Inertia output of 0.00012 kg-m2 () (0.0010 lb-in-s2); Continuous Stall Torque of 3.6 N-m (32 lb-in) and Peak stall Torque of 11.1 N-m (98 lb-in). The motor’s maximum and rated speed are both 5000 revolutions per minute (rpm). This servomotor weighs 7.4 kg (16.2 lb.) The MPS-B330P-M-X156 is already provided with a shaft seal however, replacement and servicing are recommended at least once a year or once every 3 months to maintain the environmental and protection rating. An appropriate shaft seal for use with the MPS-B330P-M-X156 is MPS-SST-F165. Shaft seals are made with Polytetrafluoroethylene (PTFE) while the shaft seal kit is included with a lubricant to reduce wear and tear of the motor. The MPS-B330P-M-X156 requires a servo drive to implement position and motion control. Via the integrated 1024 sin/cos, absolute multi-turn encoder device that supports Hiperface protocol, the motor’s rotary motion is converted to data relative to the position. This encoder communicates with compatible servo drives such as Kinetix 5500, Kinetix 5700, Kinetix 6200/6500, Kinetix 6000, Kinetix 300/350, and Kinetix 2000 servo drives.

The MPS-B330P-M-X156 is a stainless-steel servo motor that comes with a voltage rating of 400 Volts. The MPS-B330P-M-X156 features a frame size of 100 millimeters and has a magnetic stack length of 76.2 millimeters. The rated speed for the MPS-B330P-M-X156 is 5000 Revolutions Per Minute (RPM) and features the 1024 sin/cos absolute multi-turn encoder with the IEC metric tapped mounting holes or the type FT enclosure. The MPS series of stainless-steel motors comes designed to meet the unique needs of a hygienic environment. The servo motors offer the benefits of the Kinetix integrated motion and are available to a greater range of applications. They are used in high pressure highly caustic environments and to extend the wide range of the MP series motors that are used in environments requiring a high hygiene. The servo motors serve on applications for the food, the beverage, brewing, and pharmaceutical manufacturing environments. The MPS-B330P-M-X156 features as a specifically designed motor that comes as a low rotor inertia motor. It comes with a smooth passivated 300 series stainless steel enclosure. The MPS-B330P-M-X156 features NSF or the ANSI standard 169 certifications with a shaft end threaded hole and a cable extension with the IP66 or the IP67 shaft seal and uses environmentally sealed cable connectors. The MPS motor series comes with a continuous stall torque of 3.6 to 21.5 N-m with a peak stall torque of 11.1 to 98 N-m and features a speed of 3000 to 5000 Revolutions Per Minute. This servo motor series features a high-resolution feedback for a smooth operation and comes with absolute feedback option.
